Central Batching Plant
A central batching plant, also known as a central mixing plant or central mix concrete plant, is a facility where concrete is mixed centrally before being transported to the construction site. Unlike on-site or truck-mounted concrete mixers, where the mixing happens at the construction site, central batching plants consolidate the mixing process in a central location.
Here are the key features and components of a central batching plant:
Centralized Mixing Unit: The heart of the central batching plant is the mixing unit, which can be a twin-shaft mixer or a vertical-axis planetary mixer. This unit is responsible for thoroughly combining cement, aggregates, water, and any additives to produce high-quality concrete.
Aggregate Bins: Similar to other batching plants, central batching plants have multiple aggregate bins to store different sizes and types of aggregates. These bins are equipped with conveyor belts to transport aggregates to the mixing unit.
Cement Silos: Cement silos store bulk cement, and their contents are transported to the mixing unit as needed. Central batching plants may have one or more cement silos depending on the production capacity and specific requirements.
Water Storage: Central batching plants have water storage tanks or reservoirs to supply the required water for the concrete mix.
Control Room: A centralized control room houses the control panel and computer systems that manage the batching process. Operators use the control panel to input mix designs, monitor the production process, and make adjustments as necessary.
Weighing System: Accurate weighing systems for cement, aggregates, and water ensure the precise measurement of materials, contributing to the consistency of the concrete mix.
Conveyors: Conveyor belts or screw conveyors transport materials from the storage bins and silos to the mixing unit.
Batching Software: Computerized batching software is used to control and automate the batching process. It allows for the precise adjustment of mix proportions and provides real-time monitoring of the production.
Advantages of Central Batching Plants
Consistency: Central batching plants ensure consistent and uniform mixing of concrete, resulting in a higher quality product.
Control: Operators have better control over the mixing process, allowing for adjustments and optimizations.
Efficiency: Central batching plants are generally more efficient than on-site mixing, especially for large-scale projects.
Reduced Wastage: Central batching reduces material wastage as the batching process is more controlled and precise.
Cost Savings: In some cases, central batching plants can lead to cost savings in terms of labor, equipment, and materials.
Central batching plants are commonly used in large construction projects where a high volume of concrete is required, and quality control is crucial. They offer a centralized and controlled environment for producing consistent and high-quality concrete mixes.
Parameters of central batching plant
| Model |
HZS60
|
HZS90
|
HZS120
|
HZS180
|
| Theoretical capacity(m³/h) | 60 | 90 | 120 | 180 |
| Mixer model | JS1000 | JS1500 | JS2000 | JS3000 |
| Storage hopper capacity(m³) | 4*10 | 4*15 | 4*20 | 4*25 |
| Batching power(kW) | 2*18.5 | 2*22 | 2*37 | 2*45 |
| Aggregate accuracy(%) | +2 | +2 | +2 | +2 |
| Cerement accuracy(%) | +1 | +1 | +1 | +1 |
| Water accuracy(%) | +1 | +1 | +1 | +1 |
| Fly ash accuracy(%) | +1 | +1 | +1 | +1 |
| Additive accuracy(%) | +1 | +1 | +1 | +1 |
| Total power(KW) | 120 | 150 | 190 | 220 |
| Discharging height(mm) | 3800/4200 | 3800/4200 | 3800/4200 | 3800/4200 |
OUR FACTORY
Jinheng Machinery has two major production bases in Zhengzhou and Qingdao, with a production workshop of 350000 square meters. It has machining equipment such as sandblasting machines, laser CNC machine tools, drilling machines, automatic welding robots, and electronic CNC rolling machines.
As a reliable supplier to 1920 customers in the mixing industry, Jinheng Machinery combines European mixing technology and advanced design processes; We have designed over 20 concrete production lines, including a new generation of concrete mixing plants, mixing plants, and precast concrete mixing plants.
vision of the future
Building a high-quality manufacturer of green concrete mixing plants
mission
Using low-carbon concrete to create a better life for people
system of values
Gratitude, sharing, service, friendship, passion, positivity, and curiosity.
company philosophy
Integrity, exploration, innovation, breakthrough, and creation
Certifications
Create a comprehensive solution for efficient human theft manag
Certificate CE
Certificate CQC
Certificate ISO
Certificate SGS
Certificate PATENT
TRADEMARK
Our Partners
Red Star machine with a good reputation,excellent quality and sound after-sales service to win the world praise,in many domestic and foreign enterprises shine!
Why choose JHT?
We offer a variety of concrete batching plants
Rigorous production process
Raw material sandblasting and rust removal - laser cutting - strictly follow the drawings for production - one layer of primer and three layers of topcoat
High quality and low price
Cost accounting is based on the weight of raw materials (T/* USD), with a 3% service fee for purchased parts and free design
