Kyc Twin Shaft Mixer for Concrete Batching Plant

Kyc Twin Shaft Mixer for Concrete Batching Plant

Twin shaft mixer batching plant suitable for all kinds of large, medium and small prefabricated component factories and industrial and civil construction projects, such as highways, bridges, water conservancy, docks, etc.
Send Inquiry
Product Introduction

Our company, as one of the leading manufacturers and exporters in the industry, is able to provide our customers with inexpensive and well-designed Automatic Batching Plant, Cement Batching Plant, Concrete Batching Equipment. And in the process of our brand global strategic layout we welcome more and more partners join us, work together with us based on mutual benefit. Always keep in mind that we can win trust from the society with sincerity, the market with honesty, customers with sincere feelings and colleagues with sincere conduct.

Introduction

The batch concrete mixer is a kind of building material production and manufacturing equipment composed of a mixing system, weighing system, storage system, automatic control system, additional equipment, etc. Its main task is to mix and stir sand, lime powder, slag, and other materials to make concrete necessary for the construction industry. The steel body of our mixer is specially designed, and the automatic welding robot completes the material welding, so its durability is greatly improved. Liners, mixing arms, and blades are made of cast steel with high wear resistance, so the service life is longer. You can use our equipment to produce all kinds of concrete, including ready-mixed concrete, precast concrete, roller-compacted concrete, and more.


Advanced Functions

◆ Equipped with a multi-axis end face seal protection device and wind pressure seal protection device, the 2022 New batch concrete mixer can effectively prevent mud leakage;

◆ The unique monitoring system of the mixer can monitor the working status of the gearbox, unloading pump, and electric lubricating oil pump at any time;

◆ The dedicated DC24V concrete mixer centralized lubrication pump has good waterproof and dustproof performance, and its running time can be independently programmed;

◆ The multi-pipe and multi-channel water spray system can realize uniform water spray and further improve the stirring efficiency.

◆ Equipped with an enhanced gearbox and high processing precision, the 2022 New batch concrete mixer has a strong bearing capacity and a relatively long service life;

batch concrete mixer

batching concrete mixer


Data

Model

Volume
(L)

Max size of aggregate
(mm)

Engine power
(KW)

Motor RPM
(r/min)

Main shaft RPM
(rpm)

Vane Qty

Dimension

JS500

500

≤80

1*18.5

1450

35.26

18

2900*2245*2650

JS750

750

≤80

1*30

1450

28

18

3580*2150*3370

JS1000

1000

≤80

2*18.5

1450

32.2

18

3580*2150*3570

JS1500

1500

≤80

2*30

1450

22

20

2880*2310*1680

JS2000

2000

≤80

2*37

1450

26.85

32

3120*2310*1680

JS3000

3000

≤80

2*55

1450

26.85

48

4110*2530*2254


We are deeply aware that if we want to survive and develop in the fierce market, it is very important for us to bring forth new series of Kyc Twin Shaft Mixer for Concrete Batching Plant with advanced technology. We have a wealth of production and sales experience and research a number of industrial design solutions through the international advanced technology. We have become a designated supplier for many enterprises.
